MR510/2 RLS

Personal Locator Beacon

The Becker MR510/2 is a rugged, COSPAS-SARSAT certified Personal Locator Beacon (PLB) with advanced Return Link Service (RLS) capabilities, designed for civil and military aircrews, mariners, and ground personnel. Featuring multi-constellation GNSS (GPS/GLONASS/GALILEO), multi-band emergency frequencies (121.5, 243.0, 406 MHz), two-way VHF/UHF communication, and built-in self-test functionality, it ensures unparalleled reliability in critical survival situations. Compact, lightweight, and compliant with MIL-STD 810E and DO-160E standards, the MR510/2 offers both manual and automatic activation for ultimate versatility.

Interested in this Product?

Contact us for more information

NOTICE: The use of RLS beacons is not authorised in all countries. Please contact us for more information. You may also visit the webpage Countries Allowing RLS Beacons (https://cospas-sarsat.int/en/beacon-ownership/rls-enabled-beacon-purchase) to learn the most recent information about regional/global support for RLS.

Becker Avionics offers since 1970 the best in SAR technology and has delivered more than 30 000
beacons.

The new Becker´s MR510/2 is a Return Link Service Location Protocol (RLSLP) enabled and military-grade performance PLB with advanced features including a multi-constellation GNSS receiver (GPS/GLONASS/
GALILEO). The MR510/2 has a capability to receive a Return Link Message (RLM) provided by Galileo SAR Service.

Thanks to Galileo SAR service, the MR510/2 can receive and indicate COSPAS-SARSAT acknowledgement that your beacon has been accurately localised. The MR510/2 is the most advanced COSPAS-SARSAT certified handheld PLB available today. It is a rugged, multipurpose survival radio designed for civil and military aircrews, mariners and ground personnel.

Features

  • COSPAS-SARSAT certification
  • Designed for all airborne, land and marine applications
  • Multi emergency band – 121.5 MHz, 243.0 MHz and 406 MHz
  • Two-way VHF or UHF voice communication (programmable)
  • Integrated Built-In-Test features
  • Compliance with: Stanag 7007 P 1 PSAR, MIL-STD 810E, ED-14E (DO-160E)
  • Fully self-contained (transceiver, V/UHF/C-S antennas, with latest generation 72 channels GNSS
  • Compact, lightweight, state-of-the-art technology
  • Manual or automatic activation by lanyard or water immersion
  • Life vest and ejection seat capability

MR510/2 Specification
Operating frequencies F1 (VHF): 121.500 MHz ± 1.5 MHz
F2 (UHF): 243.000 MHz ± 3 MHz
F3 (UHF): 406.037 MHz
Others on request
Modulation Beacon and voice mode: AM (121.5 MHz; 243.0 MHz)
COSPAS-SARSAT: C/S Specification T.001
Antenna Tri-frequency built-in antenna and connector for external antenna
Operating temperature -20…+55 °C, Class 2
Battery Lithium type (LiSO2)
Lifetime: 5 years
BITE Self test with acoustic and optical indication for GO / NO GO
Transmitter Output power:
VHF: 100 mW
UHF: 100 mW
C/S: 5 WVoice mode F1/F2: VHF/UHF 50 mW
Modulation Mode Beacon mode:
A2X not less than 60%, audio frequency swept at 2 to 3 sweeps per second
Voice mode: A3E AM 80%
COSPAS-SARSAT: Messages C/S T.001 RLS Type-1 Acknowledgment
VHF/UHF-Receiver F1/F2 Sensitivity: -87 dBm, for 6 dB [S+N]/N, m=30%, 1 kHz
Audio output: > 100 mW, 90% modulation at 1000 Hz
GNSS receiver 72 channel, GPS L1C/A, GLONASS L1OF, Galileo E1-B/C, SBAS L1C/A
Design standards STANAG 7007
C/S T.001, C/S T.007
C/S T.012
MIL-STD-810F
ED 142/ DO-160E, ED 182/ DO-178B
RoHS-Directive
WEEE-Directive
Dimensions H×W×D 162.15 × 90 × 46.6 mm (antenna folded, storage position)
Weight < 650 g with battery
